OKUMA Machining Centers (V)MB

MB-V SERIES

Max Machining Volume (mm)——-(560 x 460 x 460)

Table Size (mm)———————–(460 x 760)

Spindle Speed (min⁻¹)—————-(15,000 [6,000])

Spindle Motor Power – Low Range (kW)—-(22/18.5 [11/7.5])

Rapid Traverse (m/min)————–(42/36)

Magazine Capacity——————-(20 [32, 48])

Max Machining Volume (mm)————–(1,050 x 560 x 460)

Table Size (mm)—————————–(1,300 x 560)

Spindle Speed (min⁻¹)———————-(50~8,000, [50~15,000, 50~20,000, 50~25,000, 50~35,000])

Spindle Motor Power – Low Range (kW)–(11/7.5 [22/18.5, 30/22, 15/11, 15])

Rapid Traverse (m/min)——————–(X-Y: 40 Z: 32)

Magazine Capacity————————-(20 [32, 48])

Max Machining Volume (mm (in) )——(1500 x 660 x 660 (59.06 x 25.98 x 25.98)

Table Size (mm (in) )———————-(1,530 x 660 (60.24 x 25.98))

Spindle Speed (min⁻¹ (rpm))————-(50-8,000, [50-15,000, 50-20,000, 50-25,000, 50-35,000 opt])

Spindle Power (kW (hp) )—————–(11/7.5 (15/10))

Rapid Traverse (m/min (ipm))————(40 /32 (1575/1260))

Magazine Capacity————————(20 [32/48 opt])

Max Machining Volume (mm)—-(1,600 x 1,050 x 600)

Table Size (mm)——————–(1,600 x 800)

Spindle Speed (min⁻¹)————-(15,000 [20,000; 12,000])

Spindle Motor Power (kW)——–(26/18.5 [30/22, 33/26])

Rapid Traverse (m/min)———–(42/32)

Magazine Capacity—————-(32 [48, 64])
